Por Precision Microdrives

Model No.304-002 - 4mm Vibration Motor - 8mm Type

Manufacturer	Precision Microdrives
Description	4mm Vibration Motor - 8mm Type
Part number	304-002
Ecc. Weight Radius	2 mm [+/- 0.2]
Ecc. Weight Length	3 mm [+/- 0.2]
Rated Operating Voltage	3 V

Rated Vibration Speed	14,100 rpm [+/- 3,600]
Typical Rated Operating Current	67 mA
Typical Norm. Amplitude	0.86 G
Body Diameter	4 mm [+/- 0.2]
Body Length	8 mm [+/- 0.2]

Modelos CAD

Solicitação de cotação

Seleção de produtos

	Model	Body Diameter	Body Length
	304-002	4 mm [+/- 0.2]	8 mm [+/- 0.2]
