M8 Female panel mount connector, Contacts: 4, shieldable, THT, IP67

M8-D, series 818, Automation Technology - Sensors and Actuators

Manufacturer	binder
Description	M8 Female panel mount connector, Contacts: 4, shieldable, THT, IP67
Part Number	86 6620 1120 00404
Mass	5.14
product segment	Automation Technology - Sensors and Actuators
numbers of contacts	4
design	Female panel mount connector
locking system	screw
termination	THT

installation type	Housing assembly
EMC	shieldable
coding	D-coded
degree of protection	IP67
Mechanical durability	> 100 Mating cycles
Rated current	4.0 A
Rated voltage	63 V DC
pollution degree	3
insulating material group	III

CAD modely

Požadavek cenové nabídky

Výběr produktu

	Part Number	Description	Mass	product segment	numbers of contacts	design	locking system	termination	installation type	EMC	coding	degree of protection	Mechanical durability	Rated current	Rated voltage	pollution degree	insulating material group
	86 6620 1120 00404	M8 Female panel mount connector, Contacts: 4, shieldable, THT, IP67	5.14	Automation Technology - Sensors and Actuators	4	Female panel mount connector	screw	THT	Housing assembly	shieldable	D-coded	IP67	> 100 Mating cycles	4.0 A	63 V DC	3	III

Popis produktu

M8 Female panel mount connector, Contacts: 4, shieldable, THT, IP67

Dokumentace

technical specification 86 6620 1120 00404
