Photoelectric Proximity Switches, Size M18W, Diffuse sensor with background suppression - operating distance 120 mm, Housing Length 75, Connector S12 version

Manufacturer	CONTRINEX
Description	Photoelectric Proximity Switches, Size M18W, Diffuse sensor with background suppression - operating distance 120 mm, Housing Length 75, Connector S12 version
Part number	LHS-1180W-301

CAD modely

Výběr produktu

	Type	Order number	Series	Size	Operating distance (mm)	Standard target	Power consumption (mA)	Emitter (nm)	Weight (g)	Compatible connection cables
	NPN light-ON / connector S12	LHS-1180W-301	1180W	M18	10 ... 120	100 x 100 mm white	25	LED red 660 nm	57	G,H,K,L
	PNP light-ON / connector S12	LHS-1180W-303	1180W	M18	10 ... 120	100 x 100 mm white	25	LED red 660 nm	57	G,H,K,L
