HLG Rails

Popis produktu

Recirculating linear guide rails from miniature to standard sizes, offering precision and quality at a competitive price.

Quick Delivery – HepcoMotion’s HLG (standard sizes) & MLG (miniature sizes) are both available from stock.
An extensive choice in sizes – Sizes range from 5mm to 20mm (MLG) and 15mm to 55mm (HLG) in European standard versions, providing greater choice and interchangeability.
A cost-effective solution – Precision and quality at competitive prices, HLG linear guide rails are suitable for many standard applications requiring accuracy and rigidity.
Ultra-smooth movement – Twin bearing track arrangement ensures smooth and rigid movement over the complete stroke length.
Small spaces – Hepco’s miniature MLG guide rails provide exceptional load capacity in a very small space; perfect for medical, scientific, and small mechanical assembly systems where high performance is demanded.

Additional Information:

• MLG is manufactured in stainless steel with standard & wide rail options, making it suitable for clean rooms
• Integral all-round block sealing prevents dirt ingress and ensures grease is retained to lubricate the internal tracks
• Range of accuracy grades and preloads to suit all applications
• Load can be applied from all directions
• A bleed lubrication system re-greases the blocks through the rail, making it easy to set up an automatic lubrication facility.
