HP- worm gear unit a=50 with clamp connection with motor flange

Quantity	Manufacturer	Description	Part number
1	Atlanta	HP- worm gear unit a=50 with clamp connection with motor flange	atlanta_5813005_6559301
1	Atlanta	motor flange cd=50	6559301
1	Atlanta	HP- worm gear unit a=50 with clamp connection without motor flange	5813005

CAD models

Product selection

Part Number

Description

worm gear unit

connection

clamp connection

centere distance a0 (mm)

ratio

4.75

Weight (kg)

6.5

Jred 10-4 (kg m2)

0.828

Part Number

Description

motor flange

centere distance a0 (mm)

D^G7

152

12.5

100

115

Weight (kg)

0.6
