Airstroke actuators Style 110

Manufacturer	Firestone
Description	Actuator with one convolution, stroke 79 mm
Part number	W01-M58-6145
Maximum height	132 mm
Stroke	79 mm
Force	36 N
Mass	1.36 kg

CAD models

Request for quotation

Product selection

	Part number	Style	Description	Assembly weight (kg)	Force (N)	Minimum height (mm)	Maximum stroke (mm)	Maximum usable height (mm)
	W01-M58-6145	110	Blind nuts, 1/4 BSP	1.36	36	53	79	132
	W01-358-0112	110	Socket head aluminum bead rings (bolts, nuts, washers not included–use M6 cap screws)	1.36	36	53	79	132

Height (mm)

Documentation
