JENKA SRA Long Inserts — Threaded Lifting System for all load directions

Product Description

JENKA Long Inserts are used in applications where sufficient anchoring depth is available. JENKA Inserts are ideal for all types of lifting operations. JENKA Long Inserts can be used for all load directions.

JENKA Long Inserts are used in concrete elements such as beams and walls, where sufficient anchoring depth is available. The minimum compressive strength of the concrete upon load application is 15 MPa. Diagonal pull between 12.5° and 45° and lateral pull at up to 90° (resulting from tilting-up) are only permitted with additional reinforcement. Standard JENKA products are always delivered galvanized. All JENKA Long Inserts are CE-marked according to the Machinery Directive 2006/42/EC. JENKA Lifting Inserts with customized lengths for special purposes are available upon request.
