AIR KNIFE SILVENT 306 L

Manufacturer Silvent HQ
Description AIR KNIFE SILVENT, Connection G 3/8", Material (nozzle) Zn
Manufacturer Part Number 03060169156
Blowing force (N) 20.4
Blowing force (lbs)
Air consumption (Nm³/h) 102
Air consumption (scfm)
Sound level (dB(A)) 85
Nozzle technology Laval
Material (nozzle) Zn
Connection G 3/8"
Connection type Female
Weight (kg) 0.6080
Weight (lbs)
Max temp (°C) 70
Max temp. (°F)
Max op. pressure (MPa) 1.0
Max op. pressure (psi)
CAD models
Request for quotation
Please make sure this software has been installed.

Product selection

Product Description

SILVENT 302 L - 306 L: with 209 L nozzles. For applications that require a curtain of air across a broad surface. Typical areas of application include air cleaning, curtains around doors and entrances, paint drying, cleaning of conveyor belts, plywood sheets etc.
