Model No.304-008 - 4mm Vibration Motor - 9mm Type

Rated Operating Voltage	1.5 V
Rated Vibration Speed	9,500 rpm [+/- 1,900]
Typical Rated Operating Current	82 mA
Typical Norm. Amplitude	0.91 G
Body Diameter	4 mm [+/- 0.2]
Shaft Orientation	Inline

Modelli CAD

Prodotto da selezionare

	Model	Body Diameter	Body Length
	304-008	4 mm [+/- 0.2]	8.6 mm [+/- 0.2]
