Safety Relay - Two-hand controller : 3Dモデル - SOLIDWORKS、Inventor、CATIA V5、AutoCAD、STEP、STL その他

カテゴリ

Wieland Electric Inc.
- Safety Relay - Two-hand controller

絞り込み

問い合わせの種類
- CADモデル付き (2)
Alternating Current Enabling Paths Rated Switching Voltage (V)
- 230 (2)
Alternating Current Rated Consumption
- 3.2 A (1)
Alternating Current Signaling Paths Rated Switching Voltage (V)
- 230 (2)
Applicable in accordance with EN 574
- Type III C (2)
Application Category AC-15 (NO)
- Ue 230 , Ie 3A (2)
Application Category DC-13 (NO)
- Ue 24 , Ie 2,5A (2)
Category (ISO 13849-1)
- 4 (2)
Contact Material
- Ag-alloy, gold-plated (2)
Creepage Distances and Clearances Between the Circuits
- EN 60664-1 (2)
Depth (mm)
- 114 (2)
Detachable Clamps
- Yes (2)
Direct Current Enabling Paths Rated Switching Voltage (V)
- 24 (2)
Direct Current Rated Consumption (W)
- 2.4 (1)
Direct Current Signaling Paths Rated Switching Voltage (V)
- 24 (2)
ECLASS 8.1 Classification
- 27371821 (2)
Electrical Isolation Supply Circuit - Control Circuit
- No (1)
- Yes (1)
Enabling Paths
- Normally open contact (2)
ETIM 3.0 Classification
- EC001452 (2)
ETIM 4.0 Classification
- EC001452 (2)
ETIM 5.0 Classification
- EC001452 (2)
ETIM 6.0 Classification
- EC001452 (2)
ETIM 7.0 Classification
- EC001452 (2)
Evaluation Inputs
- 2-Channel (2)
Feedback Circuit
- Yes (2)
Fine-Stranded with Ferrules Screw Terminal Ranges (mm²)
- 1 x 0.25 to 2.5; 2 x 0.2 to 1.0 (2)
Fine-Stranded/Solid Wire Screw Terminal Ranges (mm²)
- 1 x 0.2 to 2.5; 2 x 0.2 to 1.0 (2)
Function Display
- 3 LED, Green (2)
Height (mm)
- 96.5 (2)
Hot Functional Testing (HFT)
- 1 (2)
Input Current (Safety Circuit/Reset Circuit) (mA)
- 60 (2)
Maximum Ambient Temperature (ºC)
- 55 (2)
Maximum Enabling Paths Thermal Current Ith (A)
- 6 (2)
Maximum Fuse Insert Short-Circuit Protection (No)
- 6 A class gG fuse, fuse integral < 100 s (2)
Maximum Peak Current (Safety Circuit/Reset Circuit) (mA)
- 1000 (2)
Maximum Permissible Torque (N·m)
- 0.6 (2)
Maximum Rated Alternating Current Voltage for 50 (Hz) Frequency Controls (V)
- 26.4 (1)
- 132 (1)
Maximum Rated Direct Current Voltage for Controls (V)
- 26.4 (1)
Maximum Rated Frequency (Hz)
- 60 (2)
Maximum Resistivity, Per Channel
- ≤ (5 + (1.333 x UB / UN - 1) x 200) (2)
Maximum Resistivity, Per Channel (m)
- 100 (1)
Maximum Signaling Paths Thermal Current Ith (A)
- 2 (2)
Maximum Total Current I2 of All Current Path (A²)
- 9 (2)
Mean Time to Dangerous Failure
- 37 a (2)
Mechanical Life Time
- 107 switching cycles (2)
Minimum Ambient Temperature (ºC)
- -25 (2)
Minimum Permissible Torque (N·m)
- 0.5 (2)
Minimum Rated Control Supply Voltage at 50 (Hz) Alternating Current Frequency (V)
- 20.399999999999999 (1)
- 97.8 (1)
Minimum Rated Direct Current Voltage for Controls (V)
- 20.399999999999999 (1)
Minimum Rated Frequency (Hz)
- 50 (2)
Minimum Rated Supply Voltage at Direct Current (V)
- 20.399999999999999 (1)
Minimum Switch-On Time (ms)
- 40 (2)
Mission Time
- 20 a (2)
Model
- Basic Device (2)
Nominal Direct Current Output Voltage (V)
- 24 (2)
Nominal Voltage UN (V)
- AC 115-120 (1)
- AC/DC 24 (1)
Outputs, Safe, Delayed, with Contact
- 0 (2)
Outputs, Safe, Undelayed, with Contact
- 2 (2)
Outputs, Signaling Function, Delayed, with Contact
- 0 (2)
Outputs, Signaling Function, Undelayed, with Contact
- 1 (2)
PFHd (High Demand Mode)
- 3 E-8 1/h (2)
PL (ISO 13849-1)
- Level e (2)
Proof Test Intervall (High Demand Mode)
- 20 a (2)
Protection Degree According to DIN EN 60529 (Housing)
- IP40 (2)
Protection Degree According to DIN EN 60529 (Terminals)
- IP20 (2)
Rail Mounting Possible
- Yes (2)
Rated Control Supply Voltage at 50 (Hz) Alternating Current Frequency (V)
- 26.4 (1)
- 132 (1)
Rated Control Supply Voltage at 60 (Hz) Alternating Current Frequency (V)
- 20.399999999999999 (1)
- 97.8 (1)
REACH-SVHC CAS Numbers
- 7439-92-1 (2)
REACH-SVHC Conformity Status
- Duty-to-Declare (2)
REACH-SVHC Substances
- Lead (2)
Recovery Time TW (ms)
- > 250 (2)
Release Time TR (ms)
- < 50 (2)
Response Time TA1 (ms)
- 40 (2)
Response Time TA2 (ms)
- 40 (2)
RoHS Conformity Status
- Compliant with Exceptions (2)
RoHS Exceptions
- III-6(c) (2)
Signaling Paths
- Opener (2)
SILCL (IEC 62061)
- 3 (2)
Standards
- EN ISO 13849-1EN 62061EN 574; EN 62061; EN 574 (2)
Start Contact
- No (2)
Suitable for Monitoring of Magnetic Switches
- No (2)
Suited for Safety Functions
- Yes (2)
Synchronous Time Ts (ms)
- 500 (2)
Tightening Moment (N·m)
- 0.6 (2)
Type of Electric Connection
- Screw Connection (2)
Type of Switch Function of the Inputs
- NC/NO (2)
Weight (kg)
- 0.2 (1)
- 0.25 (1)
Width (mm)
- 22.5 (2)
With Muting Function
- No (2)
